Plug and Play AC ON/OFF Microwave Sensor

The PowerLed MC130 is a compact plug & play microwave sensor designed for quick integration into compatible LED fittings and used primarily with the ORRA-EVO range. Its quick-connect design allows the sensor to be installed directly into the fitting geartray, providing automatic ON/OFF control without requiring a separate external sensor installation. The unit operates from 220-240VAC and supports LED loads up to 200W, with a maximum mounting height of 6 metres. Integrated DIP switches allow the sensor behaviour to be configured for different environments. Detection sensitivity can be set to 25%, 50%, 75% or 100%, while selectable hold times range from 5 seconds to 30 minutes. The daylight sensor can be set to 2, 10, 30 or 50 lux, or disabled where daylight-dependent control is not required. The MC130 features Class II construction, IP20 protection and an operating temperature range of -20°C to +50°C.
